Splitting a Terraform Monolith into Four Layered Stages

There's a point in every infrastructure repo's life where the monolith becomes the problem. One root module, one state file, one terraform apply that touches everything. It's convenient at the start. Then the repo grows. A VPC change requires planning the same state file as an application Helm release. A platform upgrade serializes on the same lock as a network change. The blast radius of any mistake is the entire infrastructure.

This project had reached that point: 43 .tf files in a single root module, managing everything from VPC configuration to application Helm releases on GKE. I refactored it into four layered root modules, each with its own remote state backend in GCS — the same multi-cloud state management patterns apply even when you're single-cloud.

The Four-Stage Architecture

terraform/01-network/   — VPC, DNS zones, Cloud Armor, firewall
terraform/02-cluster/   — GKE cluster, namespaces, node pools, storage classes, service accounts
terraform/03-platform/  — Platform Helm charts: RabbitMQ, Vault, Velero, Redis, APISIX,
                          cert-manager, Grafana, external-secrets, OpenTelemetry, Falcon
terraform/04-apps/      — Application Helm releases, DNS records, IAP, GSM secrets, VMs

State backends:

gs://${gcp_project}-terraform/${cluster_name}/terraform/state/${stage}/default.tfstate

Each stage reads outputs from prior stages via data.terraform_remote_state.<stage> data sources. Cross-stage dependencies are explicit and typed, not implicit through shared variables.

Design Principles

I used the Zen of Python as a design framework, which might sound odd for Terraform work but maps cleanly:

• Explicit is better than implicit → every cross-stage dependency named via remote state outputs; no implicit variable leakage
• Simple is better than complex → tfvars at the root of each stage; no Terragrunt, no wrapper scripts
• Flat is better than nested → four stages at the same directory level, not a hierarchy
• Errors should never pass silently → tflint --minimum-failure-severity=warning gates all commits

One deliberate scope decision: destroy/cleanup logic was removed from the plan entirely. A separate zpc-infrastructure-reaper process owns sandbox resource cleanup. The refactor should not own cleanup responsibilities.

The Migration Map

All 43 monolith files were audited and mapped to their destination stage. Several required splitting:

Three new files with no monolith counterpart: 01-network/dns-zones.tf, 03-platform/locals.tf, 04-apps/locals.tf.

The Helm Provider v2 → v3 Migration

The refactor coincided with a Helm Terraform provider upgrade from v2 to v3. This was responsible for the largest category of CI failures.

Provider configuration syntax changed:

v2 used nested blocks:

kubernetes { }

v3 requires assignment syntax:

kubernetes = { }

Release block syntax changed:

Empty version strings rejected:

Helm v3 rejects version = "". The monolith had 37 app_chart_version_* variables, all with default = "". The fix was making each nullable:

variable "app_chart_version_myapp" {
  type     = string
  nullable = true
  default  = null
}

That was a bulk fix across a lot of variables. The error message from Helm v3 was clear enough, but you have to know that default = "" and default = null are meaningfully different here.

Cross-Stage Reference Errors

Moving resources between stages exposed implicit cross-stage dependencies that weren't visible in the monolith:

Namespace references: kubernetes_namespace.zpc was referenced in 03-platform/ but created in 02-cluster/. Fix: hardcode the namespace strings. The stage ordering guarantees they exist before 03-platform runs.

depends_on across stage boundaries: A depends_on = [workload_identity_binding_eso] inside 03-platform/helm.tf referenced a resource in 02-cluster. Since stage ordering already guarantees 02-cluster runs first, the dependency is redundant and was removed.

Missing data source: data.google_service_account.terraform was present in the monolith but missing from 03-platform/main.tf. Added with count = 0 for sandbox where it's unused.

The Jenkins Build Loop

Validation ran through Jenkins via the REST API, accessed through kubectl port-forward:

kubectl port-forward -n jenkins svc/jenkins 9090:8080

Builds #29 through #32 before green:

• #29/30: Helm provider v3 providers.tf syntax and vault.tf script paths
• #31: The 37 nullable variable fix
• #32: helm.tf block syntax for set_list, set_sensitive, dynamic "set"

Each failure: read the console via the REST API, diagnose root cause, fix, lint (zero errors required), commit with --force-with-lease, retrigger. The loop is mechanical once you have it set up.

Rebase Gap Analysis

The refactor branch lived for several weeks alongside active develop changes. Before merging, I ran a systematic gap analysis: every commit on develop touching terraform/ was compared against the corresponding stage-dir files.

Seven gaps: GKE version updates, APISIX config changes, image hash updates, new Redis and Helm v3 syntax in freshly merged blocks. All resolved.

This gap analysis is now documented as part of the standard merge process for the branch: before any rebase, compare develop's terraform/ commits against the stage dirs.

Result

The monolith is split. Sandbox environments run four independent state backends. The network layer can change without touching application state. Platform infrastructure can upgrade without risking application Helm releases. Each stage's blast radius is scoped to its own concerns.

The harder win was the process artifacts: a documented migration map, a rebase-and-gap-analysis workflow, and a Helm v3 migration guide embedded in project memory so the next session starts informed.
